What is a pallet conveyor roller ?
Pallet conveyor roller is a conveying system designed for moving pallets. It typically consists of a series of parallel rollers arranged in a row. The working principle involves the rotation of these rollers to move the pallets. This can be achieved either through gravity or motor-driven mechanisms. The design and spacing of the rollers ensure smooth pallet movement. Additionally, sensors and stop devices can be integrated to enhance control and efficiency.
BUY CONVEYORS AND PARTS ONLINE NOW.
Our online store is open 24/7. We have various of conveyors and parts available at discount prices for fast shipping.
Types of Pallet Conveyor Roller
At GCS, our diverse pallet conveyor rollers range caters to every need—from heavy-duty industrial rollers to lighter, more agile options—ensuring that no matter what you’re moving. The pallet conveyor rollers are crafted using metal pipes or plastic pipes and undergo stringent testing to ensure durability and performance.
◆ Gravity Roller Conveyor
This type relies on gravity and an incline to move pallets. It is suitable for light to medium loads and is commonly used for short-distance pallet transportation within warehouses.
◆ Motor-Driven Roller Conveyor
This type is driven by a motor to rotate the rollers, moving the pallets. It is suitable for heavy loads or situations where precise control is needed. A motor drives the rollers to move the pallets. Each section of the rollers can be controlled by drive cards and programmable logic controllers (PLCs) or sensors.
◆ Chain-Driven Live Roller Conveyor: This type uses a chain to drive the rollers, making it suitable for handling large and heavy loads. It is commonly used in manufacturing facilities for efficient material handling
GCS Services
It is not just about the products; it's about the experience. Our outstanding customer service goes above and beyond to support you, offering expert advice and guidance every step of the way.By choosing GCS, you’re not just getting top-tier pallet conveyor rollers—you’re partnering with a company that cares about your success and the planet’s future.
Technical Specifications
◆ Roller Diameter: Light-duty rollers typically have diameters of 38mm, 50mm, 60mm, while heavy-duty rollers have diameters of 89mm. The choice of pallet conveyor rollers diameter depends on the load weight and transportation distance.
◆ Roller Spacing: There are various options, such as 79.5mm, 119mm, 135mm, and 159mm. The pallet conveyor rollers spacing is selected based on the size of the pallets and the efficiency of transportation.
◆ Material: Typically made of stainless steel to enhance durability and corrosion resistance. Stainless steel is suitable for environments with moisture or refrigeration.
Benefits
■ Efficiency: Pallet conveyor rollers Significantly reduce the time and labor required for moving goods within a facility. For example, a motor-driven roller conveyor can quickly move pallets from one area to another.
■ Durability: High-quality roller conveyors of pallets are designed to be robust and have a long lifespan. The pallet conveyor rollers are typically made of high-strength materials to withstand heavy loads.
■ Customizability: Pallet conveyor rollers can be customized to meet the specific needs of different industries, including width, length, and load capacity. For example, the pallet conveyor rollers diameter and spacing can be selected based on the size and weight of the pallets.
■ Cost-Effectiveness: Although the initial investment of pallet conveyor rollers is relatively high, the automation of material handling processes can reduce long-term operational costs. For example, a motor-driven roller conveyor can reduce the need for manual labor.
■ Versatility: Can handle a wide range of products, from small components to large, heavy goods. For example, gravity roller conveyors are suitable for light loads, while motor-driven and chain-driven roller conveyors are suitable for heavy loads.
