When it comes to upgrading your conveyor system, polyurethane (PU) rollers are an excellent choice. They offer outstanding abrasion resistance, silent operation, and long service life. But with so many specifications available—load capacity, hardness, speed, dimensions, bearings, temperature resistance—how do you choose the right polyurethane conveyor rollers?
Let’s break it down.
Why Polyurethane Conveyor Rollers?
● ✅ Excellent wear and cut resistance
● ✅ Low noise & vibration
● ✅ Non-marking surface
● ✅ Compatibility with a wide temperature range
● ✅ Better load-bearing elasticity
Key Factors to Consider When Choosing polyurethane Conveyor Rollers
Selection Factory |
What It Means | GCS Expert Tips |
| Load Capacity (kg) | The weight the roller must support during operation. | Provide load per roller and product contact area. |
| PU Hardness (Shore A) | Affects cushioning and noise level. | Choose 70A for quiet/light loads, 80A for general use, 90–95A for heavy-duty. |
| Speed (m/s) | Impact roller balance and material wear | Let us know your line speed. We test dynamic balance before shipment. |
| Working Temperature (°C) | Important in high-heat or freezer environments. | Standard PU: -20°C to +80°C. High-temp versions available. |
| Roller Dimensions | Includes diameters, length, and wall thickness | Share your conveyor layout or drawing for accurate matching. |
| Bearing Type | Affects load, speed, and waterproofing | Options: deep groove, waterproof, low-noise sealed bearings |
PU Hardness vs Application Guide
| Shore A Hardness | Feature | Best For |
| 70A (Soft) | Quiet, high cushioning | Light items, noise-sensitive areas |
| 80A (Medium) | Balanced performance | General material handling lines |
| 90-95A (Hard) | High wear resistance, less flex | Heavy-duty load, automated system |
Why Choose GCS for Custom Polyurethane Conveyor Rollers?
■ Direct Factory Supply – Over 30 years of polyurethane conveyor roller manufacturing experience
■ Customizable Specs – Diameter, length, shaft type, bearing, color, logo
■ Premium Material – Industrial-grade PU (DuPont/Bayer), not recycled blends
■ Engineering Support – CAD drawing review & free selection consultation
■ Fast Sampling – 3–5 days for samples, mass production after approval
■ Global Shipping – Exported to North America, Europe, Southeast Asia
Common Mistakes to Avoid
× Buying based only on price without checking specs
× Choosing the wrong hardness for your application
× Overlooking dynamic balance or bearing load
× Not considering temperature and speed compatibility
Pro Tip: Always provide your expected load, speed, temperature, and roller layout. The more details, the better GCS can match your needs.
Final Thoughts
Selecting the right polyurethane conveyor roller doesn’t have to be confusing. By understanding your system’s working conditions and the roller’s performance parameters, you can make the right call—and GCS is here to help every step of the way.
